Supports CFast 2.0
Compliant with Serial ATA specifications
Support any size of CFAST memory card
The CFAST card can be the primary bootable device containing the OS and application.
CFAST Push-Push ejector on board
Powered from 15 pin SATA power connector
Transparent to the operating system and does not require any drivers
Low Profile PCI Form Factor
Includes PCI regular size and low profile 2 brackets
Occupies physical space of an empty PCI or PCIe slot in main board
Supports any Windows, Mac, Linux OS
Fully RoHS compliant
SPECIFICATIONS
Mode Name
MTB-CF110
Bus Type
Bridge Board
Chipset
N/A
Number of Ports
1-Port CFAST card (Supports CFast 2.0)
1-Port 15 pin SATA power connector
Transfer Rate
Dimensions
Operating Temperature
-10°C to 70°C
Storage Temperature
-
